Repurposed EV Battery Use: Whether you want to do off grid solar, Golf cart conversions, EV build, electric conversion car, ATV, Motorcycle, Bicycle, RV solar, and anything else that needs a battery these BMW i3 Li-Ion Battery packs will put out a lot of power and long cycle life. Tired of Lead Acid and AGM battery not performing? These repurposed EV battery Lithium Ion battery packs with 2.7kWh of power will put them to shame.
4 mounting ears on base, hole diameter = 5/16 in.
Module Voltage Limits
Max Voltage: 49.2V
Nominal Voltage: 44.4V
Min Voltage: 32.4V
Peak Current: 350A
The terminal output is designed to plug into the module next to it. We have cut that wire and put two ring terminals on each end so you can wire them into your system easier. This makes the modules much easier to use.
MODULE SPECIFICATIONS
| Number of cells | 12 |
| Construction | 12 in-series |
| Length/Total Length | 14.25″/16.125″ |
| Width | 12.25″ |
| Height | 6″ |
| Weight | 54 lbs |
| Output terminal | Custom |
| Amp Hour | 63 Ah |
| Total Voltage | 48V |
CELL SPECIFICATIONS
| Cell Type | Laminate type |
| Cathode material | LiMn2O4 with LiNiO2 |
| Anode material | Graphite |
| Rated capacity (0.3C)/td> | 63 Ah |
| Average voltage | 3.7VDC |
| Maximum Voltage | 4.1VDC |
| Minimum Voltage | 2.7VDC |
| Output terminal | Custom |
| Amp Hour | 63 Ah |
| Total Voltage | 48V |
